Multicomp Pro (R13-23A-05-BW) Pushbutton Switch, R13-23x, 12.2 mm, SPST-NO

Pushbutton Switch, R13-23x, 12.2 mm, SPST-NO, Off-(On), Round, White Product Information Pushbutton Switch Type: Standard Product Range: R13-23x Panel Cutout Diameter: 12.2mm Contact Voltage AC Nom: 250V Contact Configuration: SPST-NO Switch Operation: Off-(On) Pushbutton Actuator Style: Round Contact Current Max: 3A Actuator / Cap Colour: White Contact Current AC Max: 3A Contact Voltage VAC: 125V Contact Current DC Max: - Contact Voltage VDC: - IP Rating: - Switch Mounting: Panel Mount Switch Terminals: Solder Lug Illumination Colour: Non Illuminated Panel Cutout (H x W): - Product Overview The R13-23A-05-BW from Multicomp Pro is a pushbutton switch. Two pin momentary action Current rating of 3A at 125V and 1.5A at 250VAC Insulation resistance of 100Mohm min at DC 500V Dielectric strength of 1000VAC White ABS actuator and black ABS frame Applications Industrial, Power Management, Automation & Process Control
